* Reference-class reverb modeling processor with high-quality 24-bit/96 kHz A/D and D/A converters
* Full 4-channel operation up to 96 kHz without any limitations, providing two separate effects processors in one unit
* 8 high-end reverb algorithms, modeled after world-class reverb processors
* Additional high-quality modulation effects from X-over Delay to Chorus/Flanger plus stereo Compressor
* Full-featured digital interface with AES/EBU In/Out, optical S/PDIF In/Out, Wordclock In and MIDI function for flexible use with digital equipment
* Ultra high-resolution SHARC processor with 32-bit internal signal processing for ultimate sonic resolution
* 10 different routing types for flexible assignment of analog and digital connectors to both stereo engines
* Innovative user interface with soft push/turn encoders, big preset wheel, high-resolution graphic LCD display and additional TAP button for delay times
* Direct access to 4 effect parameters makes editing easy and comfortable
* Intuitive editing of up to 30 parameters using specially designed graphic mode
* Separate ROM and user preset banks with 400 presets total
* Balanced inputs and servo-balanced outputs with gold-plated XLR and 1/4" TRS connectors
* Open architecture allows future software updates via MIDI
* Internal switch-mode power supply for maximum flexibility (100 - 240 V~), noise-free audio, superior transient response plus lowest possible power consumption for energy saving
* Ultra-rugged construction ensures long life, even under most demanding conditions


# Analog Inputs:

* XLR Balanced
* 1/4" TRS stereo balanced

# Input Impedance: approx. 22k ohms balanced
# Maximum Input Level: +16 dBu
# Analog Outputs:

* XLR Servo-Balanced
* 1/4" TRS stereo servo-balanced

# Digital Input 1:

* Type: XLR servo-balanced
* Standard: AES/EBU or S/PDIF
* Input Impedance: 110 ohms
* Nominal Input Level: 0.2-5v peak to peak

# Digital Input 2:

* Type: TOSLINK optical
* Standard: AES/EBU or S/PDIF

# Digital Output 1:

* Type: XLR servo-balanced
* Standard: AES/EBU or S/PDIF

# Digital Output 2:

* Type: TOSLINK optical
* Standard: AES/EBU or S/PDIF

# Sync Input:

* Type: BNC
* Standard: WordClock (1x sample rate)
* Input Impedance: approx 50k ohms
* Nominal Level: 2-6v peak-to-peak

# MIDI Interface:

* Type: 5 Pin DIN jacks In/Out/Thru

# Dimensions (W x H x D): 19" x 1.75" x 8.5" (482.6mm x 44.5mm x 217mm)
