Keyboard : 88-key piano keyboard, with Touch Response
Maximum Polyphony : 128 notes
Tones :
11
Layer (excluding bass tones)
Split (Low-range bass tones only)
Effects : Brilliance (?3 to 3), Reverb (4 types), chorus (4 types), Acoustic Resonance
Beats : 0, 2, 3, 4, 5, 6
Tempo Range : 20 to 255
Number of Songs : 60
Song volume : Adjustable
Part On/Off : L, R
Number of Rhythms : 20
Tempo Range : 20 to 255
Controllers : START/STOP, SYNCHRO/FILL-IN
Modes : NORMAL, CASIO CHORD, FINGERED, FULL RANGE CHORD
Accompaniment Volume : Adjustable
Functions : Real-time recording, playback
Number of Songs : 1
Number of Tracks : 2
Capacity : Approximately 5,000 notes total
Recorded Data Protection : Built-in flash memory
Pedals : Damper (Soft and sostenuto pedal operations enabled by the optional SP-30 Pedal Unit.)
Touch Select: : 3 types, Off
Transpose : +/-1 octave (?12 to 0 to 12)
Tuning : A4 = 440.0 Hz +/-99 cents (variable)
Other Functions : Operation Lock
MIDI : 16-channel multi-timbre receive
PHONES jack :
Stereo mini jacks × 2
Output impedance: 170?
Output Voltage: 5.5V (RMS) MAX
Damper Pedal Jack : Standard jack
Power : 12V DC
MIDI OUT/IN : terminals
Speakers : (12cm × 6cm oval) × 2 (Output: 8.0W + 8.0W)
Power Requirements : AC Adaptor: AD-12
Power Consumption : 12V - 18W
Dimensions : 132.2 (W) × 27.8 (D) × 13.4 (H) cm (52 1/16 × 10 15/16 × 5 1/4 inch)
Weight : Approximately 11.4 kg (25.1 lbs)
