CD/DVD Player Section

* 1080p-compatible HDMI output
* iPod compatibility via optional Yamaha Universal Dock
* Bluetooth (A2DP) compatibility with optional Yamaha Bluetooth® Wireless Audio Receiver YBA-10
* USB port
* Front panel mini jack for connecting portable audio player
* DivX Ultra and WMV video compatibility
* Versatile format and disc compatibility

Receiver Section

* 30W x 2 high power output
* 30FM/20AM-station instant one-touch preset tuning
* Subwoofer out


CD/DVD Player Section

* 1080p-compatible HDMI output
* iPod compatibility via optional Yamaha Universal Dock
* Bluetooth (A2DP) compatibility with optional Yamaha Bluetooth® Wireless Audio Receiver YBA-10
* USB port
* Front panel mini jack for connecting portable audio player
* DivX Ultra and WMV video compatibility
* Versatile format and disc compatibility

Receiver Section

* 30W x 2 high power output
* 30FM/20AM-station instant one-touch preset tuning
* Subwoofer out



* Center Unit Dimensions (W x H x D) 8 7/16” x 4 7/16” x 11 13/16”
* Center Unit Weight 6.4 lbs.
* Format Compatibility CD-R/RW, DVD-R/RW, DVD+R/RW: WMA, MP3, MPEG-4 AAC, JPEG, DiVX Ultra, WMV
* USB: WMA, MP3, MPEG-4 AAC, JPEG
* Disc Compatibility: CD-R/RW, DVD-R/RW/R DL,DVD+R/RW/R DL
* Signal-to Noise Ratio (1 kHz) 100 dB
* Total Harmonic Distortion (1 kHz) 0.005%
* Max Power (6 ohms, 1 kHz, 10% THD) 30 W + 30 W
* Input Sensitivity (1 kHz) 400 mV
* Signal-to-Noise Ratio (IHF-A-Network, DVD, 20 W) 95 dB
* Total Harmonic Distortion (1 kHz) 0.05%
* Frequency Response (10 Hz–22 kHz) ±3 dB
