AudioSource Amp One/A Amplifier - Black from AudioSource in Home Audio

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

AudioSource Amp One/A Amplifier - Black from AudioSource in Home Audio

Be the first to review this product

Share/Bookmark

Availability: Out of stock.

$139.00

Quick Overview

AUDIOSOURCE 160W AMP 80X2 200W X1 8OHM B


* All the high-current output you need w/none of the features you don't need
* 80 watts RMS per channel stereo power amplifier w/internal bridging
* Torrodial Power Supply
* Stable into 2 ohm speaker loads
* One stereo input & one stereo auxiliary output
* Rear mounted Stereo/Bridged switch
* Truely an unbeatable power amplifier for the price
* 5 way speaker wire binding posts for bare wire or banana plugs
* 80 watts RMS per channel into 8 ohm loads
* 100 watts RMS per channel into 4 ohm loads
* 200 watts RMS bridged into 8 ohm loads
* Total Harmonic Distortion: <0.04%
* Intermodulation Distortion: <0.04%
* Frequency Response: 20Hz-20kHz, +/-0.5dB
* Signal to Noise Ratio: 110dB
* Input needed to reach full output: 0.8v
* Input Impedance: 30kohm
* Headroom: 2dB
* Dimensions: 16.5"W x 2.375"H x 11.625"D
* Weight: 14 lbs, 5 oz
condition New
Specifications

Technical specifications

General - Audio System - Connections - Power - Universal Product Identifiers

General
Product Type Amplifier
Width 16.5 in
Depth 11.6 in
Height 2.4 in
Weight 13.9 lbs
Enclosure Color Black
Enclosure Material Aluminum
Localization English
Audio System
Components 1 block(s)
Sound Output Mode Stereo
Response Bandwidth 20 - 20000 Hz
Signal-To-Noise Ratio 110 dB
Input Channel Qty 1 channel(s)
Output Channel Qty 1 channel(s)
Output Power / Total 200 Watt
Input Impedance 30 kOhm
Input Sensitivity 0.8 V
Total Harmonic Distortion 0.04%
Amplifier Output details 80 Watt - 20 - 20000 Hz - THD 0.04% - 2 channel(s) ( front ) 200 Watt - 20 - 20000 Hz - THD 0.04% - 1 channel(s) ( center )
Connections
Connector Type 1 x audio line-in ( RCA phono x 2 ) - rear 1 x audio line-out ( RCA phono x 2 ) - rear 2 x speakers output ( banana/spade ) - rear
Power
Power Device Power supply - integrated
Voltage Required AC 100/220 V ± 10% ( 50/60 Hz )
Universal Product Identifiers
Part Number AMPONE/A
UPC 0041087001078
Manufacturer Audio Source
