INPUTS: FRONT, REAR AND SUBWOOFER
OUTPUTS: FRONT, REAR AND SUBWOOFER
INDEPENDENT GAIN CONTROLS FOR EACH CHANNEL
DUAL INPUT SELECTOR
BASS BOOST ON/OFF SWITCH WITH FREQUENCY SELECTOR: 40HZ, 80HZ OR 120HZ
FREQUENCY MULTIPLIER (X1 OR X5) ON HIGHPASS OUTPUT
SELECTABLE CROSSOVER FREQUENCIES:
SUBWOOFER: 40HZ-400HZ
REAR HIGH PASS : 50HZ-1.5KHZ
FRONT HIGH PASS : 50HZ-7.5KHZ
SLOPE RATE: 12 DB/OCTAVE
SIGNAL-TO-NOISE RATIO: >90DB
GOLD PLATED CONNECTORS
REMOTE ON/OFF POWER CONTROL
LED POWER INDICATOR
SUBWOOFER PHASE & STEREO/MONO SWITCHES
DIMENSIONS (W X L X H): 8 3/4” X 5 3/4” X 1 1/2”
